Benex Panel System Overview

Benex Panel Wall & Floor Panel Systems are the ideal choice for home owners seeking thermal efficiency, acoustic performance, fire rating, ease of installation, and at the same time provide the unique quality of strength of a solid building product.


Benex panels are the lightweight alternative to traditional building products. One square meter of Benex Wall Panel weighs just 35kg, and yet has the solid feel of masonry. Its inherent strength means that no reinforcement is required, which makes cutting easy. When used as a flooring system for elevated flooring, the results are astounding. The solid nature of the system, and its excellent acoustic performance, virtually eliminates sound transmission between upstairs and downstairs living areas. Benex panels offer excellent thermal properties. When used in conjunction with other types of insulation, Benex Wall Panel Systems will achieve almost any thermal insulation requirement, the result of your home being warmer during winter and cooler in summer. The Benex Panel is 1200mm x 400mm x 35mm, and is packed on standard sized pallets for delivery. The efficiency of these dimensions means that the required amount for a typical home can be delivered on a single truck. Multiple deliveries are a thing of the past and this also results in additional cost savings.



A High Quality Building Product


  • Lightweight: With each Benex panel weighing approx. 16.8 kg, and a square meter of Benex panels weighing about 20% of a completed single skin of brick wall, installation rates are fast and require less labour. This means a saving in building costs.
  • Easy Installation Benex panels are easily handled by one person.  With the use of the recommended polyurethane adhesive and screw fixing, installation is quick and easy with no mess. Cutting is easily achieved with the use of a masonry saw.
  • Solid Feel: The smooth surface of Benex panels has a “solid” feel which is further enhanced with the application of one of the many modern acrylic render finishes and an almost limitless range of colours.
  • Accurate: Benex panels are manufactured to a tolerance of + or – 1.5mm with joints of 1-2mm easily achieved. The flush surface finish between panels allows for the application of skim coats and with minimal preparation.
  • Water Resistant: Benex panels are water resistant and correctly installed with the use of polyurethane adhesives there is no water ingression either through the panel or the joins.
  • Acoustics: Providing acoustically efficient sound transition for today’s lifestyle environment.  The Benex Panel Wall System achieved an Rw + Ctr 59
  • Termite Resistance: Benex panels contain no material that is a source of food for termites. However, it is a requirement of the Building Code of Australia that provision for termite control be made where necessary.
  • Long Life: Benex Panel will not rust, rot, delaminate or corrode.
  • Insulation: The Benex panel has an insulation value of R.4. Used in conjunction with modern insulation products, almost any required level of wall insulation is achievable.
  • Fire Resistant: The Benex Wall Panel System has achieved a 60/60/60 Fire Resistance. Download certification.
