Technical Data

Technical Specifications Summary



The complete CSIRO Test Report is provided for download below this table.  Please be warned that this report is about 100 pages long. Summaries of the findings can however be downloaded in the Technical Resources subsections listed on the left.



SPECIFICATION VALUE TEST METHOD
Acoustic Rating Hollow: Rw + Ctr 37
Core-filled: Rw + Ctr 50
Composite Wall: Rw 57
CSIRO – TL474
Thermal Rating
(R value)
Benex Wall: 0.52
Composite Wall: 2.5+
BRANZ – EC1310
Fire Rating Benex Hollow Wall: 240/240/180 CSIRO – 2042
Compressive Strength 4.92Mpa Tested By CSIRO to AS – 3700-2001
Salt Attack Resistant Tested By CSIRO to AS-NZS/ 4456.10:2003
Mortar Additive for BASE Course Required if wall is to be water impervious Krystol by Kryton Intl.
Water Resistance Rating Impervious ASTM – 51406 – CSIRO
Additional Tanking Not required
Waterproof Render Not required
Minimum Excavation Clearance 100mm at the rear of retaining wall required
Control Joints 8m max - High-grade polyurethane expansion adhesive recommended
Built Wall Heights 10m max
Wash Out Not required
Load Bearing Yes
Architectural Finish Yes
Render Finish Not required
Weight/m² of Wall Hollow: 109kg
Core-filled: 355kg

Trades Required to Build Wall 1
Fixings Minimum requirement for fixing direct to Benex is a type 17/14 gauge screw with a minimum class 3 or 4 coating CHLE – Test Certificate 3243
